vanderbiltindustries.com @VanderbiltInd Vanderbilt Industries LAN RS485 ACTpro Door Station ACTpro Door Station ACTpro Door Station ACTpro Door Controller ACTpro Door Controller ACTpro Door Controller ACTpro Door Controller 1520e eLock eLock eLock 1520e 1520e Aperio Wireless Hadleset Aperio Wireless Hadleset 1520e Aperio integration for Aperio hub up to 16 wireless door contacts per ACTpro door controller System setup ACT pro Featur es ACT pro technical specs ACT 1500 / 15002A / 1500PoE single door IP controller ACT 100 door station ACT IOM module Single Door IP Controller with Dual Ethernet switch Single door station / expander Input/output module Unlimited controllers Compatible with ACT 1500 / 15002A / 1500PoE single door IP controllers Compatible with ACT 1500 / 15002A / 1500PoE single door IP controllers Supports “OSDP” , “Clock&Data”, “Wiegand” readers Programmable inputs and outputs: push button, door contact, interlock Up to 4 x IO modules per controller 60,000 users Auxiliary relay output for alarms: door forced, door ajar, duress, door open, access granted, access denied IOM supports 8 x supervised inputs 4 Credentials per user 5Amp, 30 volt DC lock relay and a 1Amp, 24 volt DC auxiliary relay and 8 x 5 amp relays (outputs) 1,000 User Groups Tamper and voltage monitoring Tamper protection and 2 status LEDs 5,000 Stored Log Events LED status notification Output switched on/off by log event, Main Relay and Aux Relay Requires 12Volt DC supply input, timezone 12V/24V DC Power to PCB IP44 - indoor use only Typical Applications: Monitoring: Tamper, Voltage, Mains present, Breakglass Dimensions - 165 x 236 X 55 mm Elevator control IP44 - indoor use only 0.5Kg Weight CCTV switching 0.56Kg Weight ACTpro 120e includes all details above PLUS: Alarm integration Dimensions - 165 x 236 X 55mm 12 volt DC 2A PSU Dimensions - 165 x 236 x 55 mm TCP / IP - DHCP / Static IP addresses Cable management system 0.38Kg Weight Onboard ACT Enterprise LITE software Space for 1 x 7Amp Hr Battery Faults reported on controller web server or ACT software Battery deep-discharge protection Fire override Interlock/Airlock Anti passback Arm/Disarm intruder panel Muster Reporting Users Import via ACT Software Extra rights and door plan included Supports up to 32 door stations Supports up to 4 x IOM modules SECURITY • Card and User Management • User Groups & Time zones • Lock/Unlock All Doors • Real Time Events • Anti Passback • System Alarm Acknowledgment • Elevator Control • Random Challenge • • Data encryption from Card to Reader to Controller to Software (OSDP) • Affordable online internal door options (Aperio) intuitive, easy to use I/O management for trigger detection with compatible devices • Realtime view of SPC alarm zone status and events • Send commands to SPC Set/Unset, isolate/deisolate, inhibit/disinhibit and restore • Graphical maps – overlay zones onto Map • Live Video display and switching between video camera sources connected to Eventys • Playback of recorded video-sequences • Kone lift integraton for Improved security with smoother People Flow RULES MAPPING • Muster/Emergency Report (Automatic Print or Email) • Fire Panel Integration (Open all doors in the event of a fire) • Site Maps • Counting Areas HUMAN RESOURCES • Database of all employees • Import Utility to interface with HR System* • Design & Print ID Cards • Time & Attendance Report • Holidays IT • Server or Virtual Server Environment • Painless Upgrades • ACT API for 3rd Party Integrations • (Application Programming Interface)* BENEFITS • Flat system architecture • Auto device discovery • Simple to install and maintain • IP at the door Simplified processes • Highly intuitive “point and click” interface • Minimum training or technical support • Easy to quote, easy to sell • From one door to 32 to 99 to 4000 RULES MAPPING MADE EASY
